1.Company Introduction
Fancy Diamond Co., Ltd., formerly known as Luoyang Qiming Superhard Material Co., Ltd., is a modern enterprise integrating R&D, production and sales of superhard material production equipment and its products.
Our production base is located in Luoxin Industrial Cluster of Luoyang City, covering an area of about 100000㎡. It has a complete set of mechanical processing, heat treatment, assembly and commissioning production lines and the large-scale intelligent synthesis workshop. The company has an annual production capacity of 500 Sets large-scale intelligent HPHT cubic presses. And it has a large-scale HPHT diamond production workshop and complete synthesis technology. Fancy Diamond is the largest HPHT cubic press production base in the world.
The HPHT cubic press of Fancy Diamond has a number of patented inventions, and has passed the ISO9001 quality system and CE EU certification. At the same time, Fancy Diamond has a mature foreign trade team and many years of foreign trade export experience. Now our equipment has been exported to more than 20 countries such as the United States, India, UK, Russia, Germany, Spain, Japan, South Korea etc., and we have reached long-term cooperation with many Fortune 500 companies. Together with our partners, we have successfully grown the largest single lab grown diamond by weight (150.8 carats) in the world using our equipment.
2.“Turn-Key”Project
Turn-key project is a brand-new concept proposed by Fancy Diamond to serve customers in an all-round way, providing customers with technical support in the whole process from project approval to full-scale production.
The purpose of the Turn-key project is to provide technical support for our partners who have in-depth cooperation intentions or have sufficient financial strength.
Technical support includes but is not limited to:
a.Equipmentmatching/ equipment installation/ equipment maintenance/ equipment operation training.
b.Single crystal diamond synthesis/industrial diamond production, etc.
2.1.Technical support for equipment use
In the process of cooperation with customers, Fancy Diamond is mainly responsible for the following technical support,
a.If the equipment fails, it is responsible for formulating a solution, and if necessary, Fancy Diamond should send professionals to the scene to deal with it.
b.Responsible for the production or purchaseof all equipment-related accessoriessuch as anvils, steel rings, big and small blocks, sealsetc.
c.If the customer needs, we can provide synthetic cubes or carry out related technical cooperation.
If the customer needs, we can provideother auxiliary equipment, such as oven, hydraulic press, post-processing equipment, UPS, etc.
2.2.Equipment installation and debugging
Fancy Diamond has an experienced equipment assembly and commissioning team, which can meet all the needs of customers for on-site installation and commissioning. The specific work content are:
a. Install the equipment
b. Debug the equipment
c. Guide product synthesis
d. Customer operation staff training
e. After-sales service
2.3.Recommendation of equipment model according to the application direction of customer requirement
At present, the press models produced by the Fancy Diamond are mainly QMWG650—QMWG1000 and QMYG650—QMYG1000，various models can meet the production and research of superhard materials such as industrial diamond,single crystaldiamond, cubic boron nitride(CBN) and composite sheet(PDC, PCD, PCBN). Please refer to the parameters of various models of cubic presses have been listed one by one in the companys Product Operation Manual. At present, the QMYG850 press produced by our company is the main model in the market for producing superhard materials such as industrial diamond and single crystaldiamond. It has been extensively verified in various fields in the market. It has safe, stable, easy to operate and maintain , higher cost performance and other advantages.
